PRE Insulated System


PRE INSULATED pipes and fittings are insulated with high energy efficient (HE) foam and protected with a robust jacket. It is a corrosion and condensation free solution for the transport of chilled water inside residential and commercial buildings as well as data centres and for process cooling. The smooth inner surface of the thermoplastic PE pipe provides a minimum pressure loss while the low thermal conductivity of the insulation ensures reduced energy loss and running costs for a life time. The 3-in-1 construction keeps installation time to a minimum.


Dimensions : d20 – d315

Media Pipe – Material : PE 100

Insulation – Material : HE foam, CFC free, closed cell

Pressure rating : upto 16 bar

Temperature range : -51°C to +60°C

Main Advantages

  • 50% faster installation
  • 30% better energy efficiency
  • 100% corrosion free
  • Fast connection, easy suspension
  • Excellent insulating properties, low operational and energy costs
  • No corrosion
  • Low CO2 emissions

Main Applications

  • Breweries & Frozen food
  • Glycol and chill brine handling
  • Water Treatment
  • Food & Beverage / Cooling
  • Marine
  • Building Technology
